This instrument operates on the principle of contact measurement to determine the moisture content in paper products. It functions by assessing the electrical conductivity between two electrodes that come into direct contact with the paper. As the moisture level within the paper alters the conductivity, this change is accurately measured, providing a precise moisture reading. This method is widely used due to its direct and reliable results in monitoring the moisture content.
This instrument uses contact measurement. The moisture of the paper product is measured by measuring the electrical conductivity between two electrodes.
Can communicate with PC computer for statistics and printing by USB cable or Bluetooth adapter.
Automatic power off to conserve power.
Can store 240 groups of measurements.
Digital display gives exact reading with no guessing or errors while a colour coded light (LED) indicates the moisture condition of the material. This combined presentation of moisture measurement helps the user to map the extent of problems and monitor changes in condition precisely and reliably.
Sensor Type | Contact Type | |
Range | 0~50% (Cd08), 0~18% (Cd10), 0~100% (Cd11), 0~40% (Cd12) | |
Accuracy | ±(0.5%n+1) | |
Resolution | 0.1 | |
Display | LCD | |
LED Indicator | Green LED represents a safe, air-dry state | |
Yellow LED represents a borderline state | ||
Red LED represents a damp state | ||
The Statistics Available | Last value / Mean value / Max. value / Min. value / Number of Readings | |
Memor | 240 groups | |
Operating | Temperature | 0~50°C |
Conditions | Humidity | < 90%RH |
Power Supply | 4x1.5V AAA (UM-4) Battery | |
Dimensions | Main Unit: 150x65x30mm | |
Sensor: 265x44x44mm | ||
Length of electrode: 77mm | ||
Cross section size of electrode: 14x1mm | ||
Gap between 2 electrodes: 4mm | ||
Weight | 280 g (Not Including Batteries) | |
Standard Accessories | Main Unit | |
Sensor | ||
Carrying Case(B04) | ||
Operation Manual | ||
Optional Accessories | USB Data Cable with Software | |
Bluetooth Data Adapter with Software |
